Low Pass 30MHZ EMI EMC Filter For Large Automatic Equipment
Technical Specification:
| Item | Power line Filter |
| Model | YB35F2-30A-S |
| Transfer Function | Low Pass |
| Package Type | Surface Mount |
| Nominal Center Frequency | 10K-30MHZ |
| Insertion Loss | 60~90dB |
| Input Impedance | 50Ω |
| Rated Voltage | 115V/250V |
| Rated Current | 1~50A |
| Environmental Temperature | 40°C |
| Temperature Range | 25 / 085 / 21 |
| Operating Frequency | 50/60HZ |
| Line to Line | 1450VDC |
| Line to Ground | 2250VDC |
| Maximum Leakage Current | 250VAC/60HZ 0.8mA Max |
| MOQ | 10pcs |
| Price | Negotiable |
| Lead Time | 3~4 weeks |
Features:
-- Designed 2 stage enhanced filtering to prevent the power supply may produce interference to the device
-- Standard filters are a practical solution, which can helping you to pass EMI system test in a short time
Typical Applications:
-- Electrical and electronic equipment
-- Various terminal options allow you to select.
Rule of Nomination:
YB 35 F2 - 30A - S
¦ ¦ ¦ ¦
circuit case current connection
*Q: Fast-on 6.35x0.8mm S: Screw lug W: UL1015 18awg
Electrical schematic:
Mechanical Dimension(Unit: mm)
Insertion loss table(In 50ohm system according IEC/CISPR No.17)
Common mode -------- differential mode
