Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment

Place of Origin China/shenzhen
Brand Name YBX
Certification UL, TUV, CE, CQC, ROHS
Model Number YB11E1-10A-Q
Minimum Order Quantity negotiation
Price negotiation
Packaging Details standard packaging
Delivery Time 7-15days
Payment Terms L/C, T/T
Supply Ability 100000 Piece/Pieces per Month
Product Details
Overload Current Socket EMI Filter Rated Voltage 250/440VAC
Rated Current 10A Line To Line 1450VDC
Line To Ground 2250VDC Insertion Loss 60~100dB
High Light

AC 250V Socket EMI Filter

,

Low Pass Socket EMI Filter

,

10A electrical power line filters

Leave a Message
Product Description

Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment



emi filter 10A low pass electrical and electronic equipment





Description



Performance driven EMI filters are used to regulate and protect sensitive electronics from interference. These EMI filters not only drive technology, but are also used in other fields such as telecommunications. EMI filters protect all kinds of electrical apparatus, as all electrical and electronic appliances, equipment and systems have the potential to disturb other ones. Therefore, this must prevent such electromagnetic interference to a level which is acceptable to it’s surroundings. Therefore the noise emission must be low.



Feature



Product name: AC Socket EMI Filter
Rated voltage: AC 250V, 50/60Hz
Rated current: 10A
Number of positions: 3
Mounting type: Panel mount, flange; through hole
Termination: Solder quick connect
Material: Metal & plastic



Specification Of EMI Power Filter



Item

single-phase EMI FILTER

Rated Current

10A

Model

YB11E1-10A-Q

Environmental Temperature

40°C

Transfer Function

Low Pass

Temperature Range

25 / 085 / 21

Package Type

Surface Mount

Operating Frequency

50/60HZ

Nominal Center Frequency

10K-30MHZ

Line to Line

1450VDC

Insertion Loss

50~100dB

Line to Ground

2250VDC

Rated Voltage

250/115VAC

Maximum Leakage Current

220VAC/60HZ  3-10mA Max

Flammability corresponding to

UL 94V-0

MOQ

Negotiable

Lead Time

7-15 weekday

Price

Negotiable





Applications:



Hybrid vehicles; fuel cell vehicles; 42V power supply DC/DC converters; electric vehicle chargers; transmitters and receivers of sensors, etc.Electronic data processing and office equipment: personal computers; printers; computer peripherals; fax machines; copiers ;Monitor; plotter; computer host drive and control equipment: frequency converter; inverter



Advantages:



  1. After years of efforts of the company's personnel, products successively obtained the cUL,
    TUV,CQC, CE, ROSH certifications.
  2. We have a professional R&D team; our aims is we won't let customers spend any extra money!
  3. National high-tech enterprises, brand assurance, reliable quality, and we have the relevant

product certifications.

  1. We cooperate with top scientific research laboratories to provide free EMC rectification technical

support, samples; and free conduction test.

  1. Automation technology, scale production, great price,excellent, service, fast delivery! Free replacement within three months, free maintenance within six years, life-long maintenance!



Naming Rule:



YB 11-------E1----------10A-------------S/T/B

        |            |                |                    |

   circuit     case        current         connection

                                                     S: Screw

                                                     T: Terminal Block

                                                     B: Copper bar


Electrical Schematic



Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 0





Drawing:


Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 1







Factory Picture

Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 2

Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 3

Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 4

Low Pass AC 250V Socket EMI Filter 10A For Electrical Equipment 5





Our Services

Before-sale

After-sale

1. All inquires will be replied with 8 hours. 7D/24H service, please feel free to contact us with Email/TM/Skype

1. All EMI filters will be tested and adjusted before shipping.

2. Strong technical team and professional sales.

2. After receiving the products, any questions we will try our best to solve.

3. Customized packaging is acceptable.

3. Free replacement within three months, free maintenance within six years,

life-long maintenance!

4. We supply free samples and EMC technical rectification services







FAQ

1. What can you supply?

A: We can supply custom EMI Power Filter, EMI EMC Filter and so on, all kinds of EMI Filter.



2. Are OEM and ODM available?

*  Yes, they are. As a professional EMI Power Filter manufacturer, we offer OEM and ODM service.



Q: What are your main products?

A: Our main products are EMI Power Filter.



4. How about your product warranty?

*  We offer one-year warranty upon delivery.



5. How about the aftersales support?

*  We will offer on-time response for online inquiries from overseas users. Please feel free to tact us by email, Ali-Trade, WhatsApp, WeChat and SKYPE.
