Place of Origin:
CHINA
Brand Name:
YBX
Certification:
CUL ISO9001 CE CQC ROHS TU
Model Number:
YB41F3-30A-S
Contact Us
Video
Video
The YB41F3-30A-S EMI Filter, with a rated voltage of 115V/250V and a rated current ranging from 20A to 200A, operates effectively in environments with temperatures up to 40°C. It boasts a wide temperature range of 25°C to 85°C, making it suitable for various applications. This filter operates at frequencies of 50/60Hz, providing robust performance. With a line-to-line voltage of 1450VDC and a line-to-ground voltage of 2250VDC or 2000VAC, it ensures reliable electrical isolation. It meets stringent industry standards with certifications including cUL, ISO9001, CE, CQC, ROHS, and TU. This EMI filter, designed with a low pass transfer function, delivers an insertion loss of 30 to 60dB, effectively attenuating unwanted noise. Its nominal center frequency ranges from 10kHz to 30MHz, with a 3dB bandwidth of 14K. With an input impedance of 50Ω and a stopband attenuation of 20 to 100dB, it provides exceptional performance and reliability for your application needs.
| Model Number | YB41F3-30A-S |
| Rated Voltage | 115V/250V |
| Rated Current | 20A-200A |
| Environmental Temp | 40°C |
| Operating Frequency | 50/60HZ |
| Insertion Loss | 30--60db |
Our Company:
Customized Solutions: With a dedicated R&D team, our goal is to ensure that customers don't incur any unnecessary expenses.
Listed Company: As a national high-tech enterprise, we offer brand assurance and reliable quality, backed by relevant product certifications.
EMC Rectification Testing: We collaborate with leading scientific research laboratories to offer free EMC rectification technical support, samples, and complimentary conduction tests.
Scale Production: Leveraging automation technology, we achieve scale production, offering competitive pricing, excellent service, and fast delivery. We provide free replacements within three months, free maintenance within six years, and lifelong maintenance support.
Our Advantages:
Accredited Products: Through the dedicated efforts of our team, our products have obtained prestigious certifications including cUL, TUV, CQC, CE, and ROSH.
Customized Solutions: With a professional R&D team at our disposal, our commitment is to ensure that customers never incur unnecessary expenses.
High-Tech Enterprise: As a recognized national high-tech enterprise, we guarantee brand assurance and consistent quality, with all necessary product certifications in place.
EMC Technical Support: We collaborate with leading scientific research laboratories to offer complimentary EMC rectification technical support, samples, and conductive testing at no extra cost.
Efficient Production: Leveraging automation technology, we ensure scale production, providing competitive pricing, exceptional service, and swift delivery. We offer free replacements within three months, free maintenance for six years, and lifelong maintenance support.
