Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment
Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment

Large Image :  Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment

Product Details:
Place of Origin: China
Brand Name: YBX
Certification: UL, TUV, CE, CQC, ROHS
Model Number: YB11P5-6A-S
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 56.5*28.5*20.5CM
Delivery Time: 15-25 days
Payment Terms: T/T, L/C
Supply Ability: 23000pcs/month

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment

Description
Material: Plastic Installation: Surface Mount
Color: Black Voltage: 115-250v
Current: 1A-10A Connection: Solder
Frequency: 50/60HZ Temperature Range: -25°C~+85°C(25/85/21)
Certificates: CUL,UL,TUV, CE, CQC, ROHS
High Light:

250V 10A Single Phase RFI Filter

,

Surface mount Single Phase RFI Filter

,

LCR single phase emi filter

compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment



250V 1-10A LCR common-mode single phase RFI filters with compact size for electric equipment

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 0

Technical Data Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 1

Brand YBX
Part Number YB11P5-6A-S
Rated voltage 115/250VAC,50/60Hz
Operating frequency DC to 60Hz
Rated currents 1-10A@40°C
Hipot Rating L-L 1450VDC
  L/N-G 2250VDC
Leakage current 0.4mA 60HZ
  0.8mA 50HZ
IR: 50M ohm AT 500VDC any input or output to ground
Climatic category -25°C~+85°C(25/85/21)
Design corresponding to UL1283, CSA C22.2 No.8,
  IEC/EN 60939,
  CQC GB 15288/GB 15287-2008
Flammability UL 94V-0



Typical Applications

  • Electrical and electronic equipment
  • Medical equipment
  • Datacom equipment
  • Office automation equipment

Features

  • The compact size can be applied to various situations.
  • There are a variety of parts and combinations to meet different customer's EMC tests
  • Customized products according to customer's requirements

Rule of Nomination

YB       11      P5      -6A       -S

             I         I         I            I

       Circuit  case  current  connection



Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 2S: Screw lug



Electrical schematic

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 3

Mechanical Dimension(mm)

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 4

Insertion loss table(In 50ohm system according IEC/CISPR No.17)

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 5

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 6

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 7

Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 8Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 9Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 10Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 11Compact 250V 10A LCR Single Phase RFI Filter For Electric Equipment 12

Single Phase Filter:



cUL:20190321-E471748



TUV:B0899310001Rev.01



CQC:19001226449



CE:SZAIS180620005-01



CB:CN49286



ROHS:MMCRHRWM60371744



Three Phase Filter:



cUL:20190325-E502442



ENEC:ENEC-02580



CE:SZAIS180620005-01



ROHS:MMCRHRWM60371744



Our Advantages

1.After years of efforts of the company's personnel, products successively obtained the cUL,
TUV,CQC, CE, ROSH certifications.

2.We have a professional R&D team; our aims is we won't let customers spend any extra money!

3.National high-tech enterprises, brand assurance, reliable quality, and we have the relevant

product certifications.

4.We cooperate with top scientific research laboratories to provide free EMC rectification technical

support, samples; and free conduction test.

5.Automation technology, scale production, great price,excellent, service, fast delivery! Free replacement

within three months, free maintenance within six years, life-long maintenance!



FAQ:

Q1:Do you offer customized product ?

A: Yes, we can develop new mold at you need if you can provide us with the samples or drawings and specification.



Q2: Are you a factory?

A: Yes, we are the professional manufacturer of EMI filter designing and manufacturing since 2008.



Q3: How long is the delivery time?

A: We ensure the fast delivery. Generally, it will take 2-5 days for sampels; 10 to 15 for small orders, 15-25days for mass production after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Please contact us for details.



Q4: How about the payment terms?

A: We usually require T/T in advance. If the amount is more than 5000USD, we can do 30% T/T deposit , 70% T/T deposit before shipment and balance against shipment .And we also accept the L/C, Western Union , paypal etc.



Q5: How about the certificates?

A:ISO 9001, CE, TUV, UL, ROHS, ENEC, REACH etc.



Q6: How about the sample?

A: Free samples. You need to pay for currier cost. Please contact us for details.
